Gigabyte X870E AERO X3D DK WOOD AM5 DDR5 256GB USB4 Wi-Fi7 MT7927, RZ738 5GbE PCIe5 M.2 PCIe5/4 HDMI ALC1220 ATX | X870E AERO X DK WOOD 1.0

Gigabyte X870E AERO X3D DK WOOD AM5 DDR5 256GB USB4 Wi-Fi7 MT7927, RZ738 5GbE PCIe5 M.2 PCIe5/4 HDMI ALC1220 ATX

CPU
AMD Socket AM5, support for:
AMD Ryzen™ 9000 Series Processors/
AMD Ryzen™ 8000 Series Processors/
AMD Ryzen™ 7000 Series Processors

Chipset
AMD X870E

Memory
4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory

Audio
Realtek® ALC1220 CODEC

LAN
2 x Realtek® 5GbE LAN chips (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)

Unique Features
Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup

Operating System
Support for Windows 11 64-bit
Form Factor
ATX Form Factor; 30.5cm x 24.4cm

Product Last Updated: 24/09/2026

* Whilst we endevour to have the correct information on our products provided from the supplier/manufacturer errors do occur. If you would like to double check the information, please feel free to contact us and we will be more than happy to confirm information on the item prior to purchase. In the event that product information is incorrect due to information we received from our supplier or manufacturer, we do not take responsibility or be held liable for damage(s) or loss(s). We will work with you and do our best to make the best of a bad situation and work with our supplier(s) and/or manufacturer(s) to supply the correct information for the item purchased etc..
