Corsair FRAME 4000D Vault Series Modular Mid-Tower PC Case – Nova, ATX/E-ATX, TG panel, modular, 430mm GPU, 170mm CPU clr, 360mm rad, (LIMITED EDITION | CC-9011343-WW

Corsair FRAME 4000D Vault Series Modular Mid-Tower PC Case – Nova, ATX/E-ATX, TG panel, modular, 430mm GPU, 170mm CPU clr, 360mm rad, USB-C, 2yr wty

•Chromatic paint that shifts color with viewing angle and lighting
•Aluminum badge with limited edition etching, only 1337 of each color made
•Full-Tempered Glass Side Panel and Compact PSU Shroud
•Modern Front I/O panel with 3x USB Type-C ports
•InfiniRail™ Fan Mounting System for easier building
•Dual 360mm radiator support
•GPU Anti-sag Stabilization Arm
•Compatible with reverse connector motherboards including ASUS BTF, MSI PROJECT ZERO, and GIGABYTE PROJECT STEALTH

Color: NOVA

Tech Specs
Case Supported
Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm)

Case Height
486mm

Case Length
490mm

Case Width
239mm

Material
Steel, Tempered Glass, Plastic

Color
WHITE

Case Size
Mid-Tower

Radiator Compatibility
120mm, 140mm, 240mm, 280mm, 360mm

Case Window
Tempered Glass

Compatible Liquid Coolers
H60, H100, H115, H150, NAUTILUS, TITAN

Case Warranty
2 Year

Internal 3.5′ Drive Bays
1

Internal 2.5′ Drive Bays
2

Maximum CPU Cooler Height
170mm

Maximum PSU Length
220mm

Case Front IO
(1x) USB 3.2 Gen 2×2 Type-C, (2x) USB 3.2 Gen 1 Type-C, (1x) Audio in/out

Maximum GPU Length
430mm

Weight
12.54kg

Case Expansion Slots
7 Horizontal or 3 Vertical

Case Power Supply
ATX

Radiator Support – Top
360mm, 280mm, 240mm

Radiator Support – Front
360mm, 280mm, 240mm

Radiator Support – Bottom
None

Radiator Support – Side
360mm, 280mm, 240mm

Radiator Support – Rear
140mm, 120mm

Fan Support – Top
3x 120mm, 2x 140mm

Fan Support – Front
3x 120mm, 2x 140mm, 2x 200mm

Fan Support – Bottom
3x 120mm

Fan Support – Side
3x 120mm; 2x 140mm

Fan Support – Rear
1x 120mm, 1x 140mm

Front IO Motherboard Connections
1x USB-3.2 Gen2x2 Type-E, 1x USB 3.2 Gen1 20-Pin, 1x F_PANEL, 1x HD Audio

Reverse Connector Motherboard Support
Yes

Included Fans
No Fans Included

Dust Filtration
Yes

Cable Routing Space
37mm

RapidRoute Included
No

Left Side Panel
Tempered Glass

Right Side Panel
Steel

Vertical Mount Support
Supported (Riser Card Sold Separately)

Product Last Updated: 10/04/2026
