Western Digital G-RAID SHUTTLE 4 48TB APJP, Thunderbolt 3, USB 3.2 Gen 2×1, Ultrastar 7200 RPM, DTR Up to 700MB/s read and 850MB/s write, 5 Y Warranty | SDPH34H-048T-SBAAB

Western Digital G-RAID SHUTTLE 4 48TB APJP, Thunderbolt 3, USB 3.2 Gen 2×1, Ultrastar 7200 RPM, DTR Up to 700MB/s read and 850MB/s write, 5 Y Warranty

G-RAID SHUTTLE 4. Transportable, Hardware RAID Powerhouse

A transportable 4-bay hardware RAID solution with Thunderbolt™ 3 (40Gbps) and USB-C™ (10Gbps) interfaces offering content professionals up to 104TB1 of massive capacity and high-powered performance for consolidated backup, super-fast access, and real-time video editing. Supports multi-stream 4K, 8K, and VR workflows, RAID 0, 1, 5, and 10 configurations, and provides transfer rates up to 700MB/s read and 850MB/s write2 in default RAID 5 (96TB model only). Along with Ultrastar enterprise-class hard drives inside for enhanced reliability and a trusted 5-year limited warranty, the G-RAID SHUTTLE 4 is the ultimate storage solution for demanding video workflows on location and in the studio.

Ideal Capacities for Demanding Production Workflows
Available in capacities up to 104TB1, the G-RAID SHUTTLE 4 device delivers high performance storage to save all your favorite 4K or 8K high dynamic range (HDR) and high frame rate (HFR) footage in a single location.

Removable, Ultrastar Enterprise-class 7200RPM Hard Drives
For all your demanding workloads and mission-critical footage, you can depend on the power and enhanced reliability of four (4) removable Ultrastar enterprise-class 7200RPM hard drives inside.

Up To 700MB/s sustained read speeds in RAID 5
With speeds up to 700MB/s read and 850MB/s write2 in default RAID 5 (96TB model only), the G-RAID SHUTTLE 4 device delivers the performance you need to quickly ingest content and natively edit footage to make changes in real-time.

Transportable Design
Built for easy travel between your on-site production location and to the studio for post-production, the G-RAID SHUTTLE 4 device delivers powerful, transportable storage to help improve your workflow efficiency, wherever you are.

Optimized Support For Multi-Stream Workflows
Built for multi-stream 4K and 8K production workflows, the G-RAID SHUTTLE 4 device offers the bandwidth to support multi camera editing in real time, render footage with multi-layer effects, and quickly export in an efficient workflow.

Built-in Hardware RAID
For maximum performance, the SanDisk G-RAID SHUTTLE 4 comes in RAID 5 out of the box and supports RAID 0, 1, and 10 to provide a versatile and flexible storage solution.

Daisy-chaining for up to 5 Additional Devices
With dual Thunderbolt 3 ports, you can conveniently daisy chain up to 5 additional devices, keeping you connected to multiple drives, 4K displays and more, through a single connection to your computer.

5-Year Limited Warranty
Backed by a 5-year limited warranty, you can be confident in the reliable storage of the G-RAID SHUTTLE 4 for years to come.

Specifications

Capacity
48TB

Connector
Thunderbolt 3
USB-C

Sequential Read Performance
(In default RAID 0) – Up to 1000MB/s

Sequential Write Performance
(In default RAID 0) – Up to 1100MB/s

Interface
USB 3.2 Gen 1
Thunderbolt 3

Disk Speed (RPM)
7200 RPM

Warranty
5-Year Limited Warranty

Dimensions (L x W x H)
9.75′ x 6.85′ x 10.5′

Weight
7.4kg

Certifications
FCC-ICES, CE, RCM, BIS, VCCI, KC, EAC, SABER, LoA, BSMI, UAE, UKCA

Product Features
Optimized multi-stream workflows
Daisy-chaining for up to 5 additional devices
Built-in hardware RAID

Compatibility
macOS 11+
Windows 10+ (via reformat)
