ViewSonic ViewBoard IFP86G1 86′ 4K OS-Free Interactive Display, BYOD, Upgradable framework, USB-C plug-and-play Flexible integration with slot-in PCs | IFP86G1

ViewBoard IFP86G1
Genesis Series 86′ 4K OS-Free Interactive Display
Bring Your Own Device interactive display for versatile use in any scenario
Upgradable framework for enhanced versatility and prolonged longevity
Seamless USB-C plug-and-play connectivity with 65W power charging for convenient presentations
Flexible integration with slot-in PCs, supporting Windows, Linux, and EDLA

Panel Size: 86′
Panel Type: TFT LCD Module with DLED Backlight.
Display Area (mm): 1895.04 (H) X 1065.96 (V)
Aspect Ratio: 16:9
Resolution: UHD 3840×2160
Colors: 1.07G
Brightness: 400 nits (typ.)
Contrast Ratio: 4000:1 (typ.) 6000:1 (DCR)

Touch
Type/ Tech: Ultra Fine Touch Techology (IR Recognition)
Touch Resolution: 32767 × 32767
Touch Point: Windows: 40 points of touch, Android : 20 points of touch
INPUT
HDMI: Rear 2.0 x 3 (HDMI 1 3 Support CEC; HDMI 2 Supports CEC ARC)
RGB / VGA: x1
Audio: x1
RS232: x1
OPS: x1
OUTPUT
Audio: x1
LAN
RJ45: 1 in 1 out
USB
Type A: Front x3(USB2.0x1, USB3.0x2)
Rear x3(USB3.0x2, 2.0 x1 for FW update)
Type B: Rear x2 (USB 3.0×2)
Type C: x1 ( DP 1.2, Touch, Data Sharing, PD65W, Ethernet 10M/100M)
SPEAKERS
10W x 2
Top Camera Plate
Yes
COMPATIBILITY
HDMI: 3840×2160 @ 60Hz
Special Features
All-in-one USB port: “SmartPort™ USB’ to all channels.
Simple LAN sharing between IFP and slot-in device: 10/100/1000M (USB Type-C 10M/100M, OPS 1000M)
Light Sensor: Yes

Slot in PC: VPC37-W53-G1

Product Last Updated: 11/12/2025
