MSI MPG B760I EDGE WIFI Motherboard, 2x DDR5~128GB, 1x PCI-E x16, 2x M.2, 4x SATA, 4x USB 2.0, 2x USB C | MPG B760I EDGE WIFI

MSI MPG B760I EDGE WIFI Motherboard, 2x DDR5~128GB, 1x PCI-E x16, 2x M.2, 4x SATA, 4x USB 2.0, 2x USB C

SPECIFICATIONS:
CHIPSET INTEL B760
CPU SUPPORT Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700
MEMORY 2x DDR5, Maximum Memory Capacity 128GB
STORAGE 2x M.2, 4x SATA 6G
ONBOARD GRAPHICS 1x HDMI™ Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz*
1x DisplayPort Support DP 1.4, maximum resolution of 8K 60Hz
SLOT 1x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)

USB 2x USB 2.0 (Rear)
2x USB 2.0 (Front)
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
1x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Rear)
1x USB 10Gbps Type C (Front)

WIRELESS LAN BLUETOOTH Intel® Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.3, FIPS, FISMA

INTERNAL IO 1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
1x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)

Product Last Updated: 11/12/2025
