GIGABYTE Gen3 512GB NVMe PCIe 3.0 x4 M.2 2280 SSD, 1900MB/s Read, 1200MB/s Write, 1.5M Hours MTBF, 3-Year Warranty | G3NVME512G M.2 512GB

GIGABYTE Gen3 512GB NVMe PCIe 3.0 x4 M.2 2280 SSD, 1900MB/s Read, 1200MB/s Write, 1.5M Hours MTBF, 3-Year Warranty

Specification

Interface
PCI-Express 3.0 x4, NVMe 1.4

Form Factor
M.2 2280

Total Capacity
512GB

NAND
3D TLC NAND Flash

External DDR Cache
N/A

Sequential Read speed
Up to 1,900 MB/s

Sequential Write speed
Up to 1,200MB/s

Dimension
80 x 22 x 2.3 mm

Mean time between failure (MTBF)
1.5 million hours

Max. Operating Power
Read : 3.2W; Write : 3.2W

Power Consumption (Idle, PS3)
35mW

Power Consumption(PS4, L1.2)
5mW

Temperature (Operating)
0°C to 70°C

Temperature (Storage)
-40°C to 85°C
