(Clamshell Or Installed On MBs) AMD Ryzen 5 1600 ‘TRAY’, YD1600BBM6IAE 6 Core/12 Threads AM4 CPU, No Fan, 1YW (AMDCPU)(AMDBOX)(TRAY-P) | YD1600BBM6IAE

Product ID Tray
YD1600BBM6IAE

Specifications
Platform
Boxed Processor
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 5 Desktop Processors
# of CPU Cores
6
# of Threads
12
Max. Boost Clock
Up to 3.6GHz
Base Clock
3.2GHz
Total L1 Cache
576KB
Total L2 Cache
3MB
Total L3 Cache
16MB
Default TDP
65W
Processor Technology for CPU Cores
14nm
Unlocked for Overclocking
Yes
CPU Socket
AM4
Thermal Solution (PIB)
Wraith Spire (No LED)
Thermal Solution (MPK)
Wraith Spire
Max. Operating Temperature (Tjmax)
95°C
Launch Date
4/11/2017
*OS Support
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
PCI Express® Version
PCIe 3.0 x16
System Memory Type
DDR4
Memory Channels
2
System Memory Specification
Up to 2667MHz

Key Features
Supported Technologies
AMD SenseMI Technology
AMD ‘Zen’ Core Architecture
AMD Ryzen™ Master Utility
Virtualization
Enmotus FuzeDrive™ for AMD Ryzen™
AES
AVX2
FMA3
XFR (Extended Frequency Range)

Product Last Updated: 23/11/2025
