Brateck Modular Mechanical Spring Triple Monitor Arm with Sliders 17′-27′ Monitor Weight Capacity (per flat screen):11kg, VESA: 75×75,100×100(Black) | LDT86S-C034S-BLK

Brateck Modular Mechanical Spring Triple Monitor Arm with Sliders 17′-27′ Monitor Weight Capacity (per flat screen):11kg, VESA: 75×75,100×100(Black)

Combine exceptional quality with innovative design. The one-way bearing mechanism and one-touch height adjustment ensure smooth, effortless monitor positioning, while precision sliders deliver seamless alignment of monitors. Installation is quick and hassle-free thanks to the user-friendly quick-release VESA plate and top-mount base. Crafted from premium materials and available in three colors, it provides a high-performance solution that enhances both functionality and aesthetics in any workspace.

FEATURES
●One-Way Bearing Head Tilting Structure: eliminates friction when tilting for effortless adjustment
●Quick-Release VESA Plate: for easy installation and removal
●Universal Sliders: allow the monitors at a proper ergonomic distance
●Installs from Top Side: installs entirely from above the desk surface
●Wide Range of Movements: allows screen tilting, swiveling, rotation and height adjustments for optimum viewing
●Built-in Cable Management: for an organized and neat workspace

SPECIFICATIONS
Product Category: Mechanical Spring Monitor Arm
Rank: Super Premium
Material: Aluminum,Steel,Plastic
Surface Finish: Paint Spraying
Color: White,Gloss Grey,Black
Dimensions: 1378x136x825mm (54.3’x5.4’x32.5′)
Fit Screen Size: 17′-27′
Fit Curved Monitor: Yes
Screen Quantity: 3
Weight Capacity (per screen): 2-11kg (4.4lbs-24.2lbs)
Weight Capacity for Curved Screen (per screen): 2~10kg (4.4lbs~22lbs)
VESA Compatible: 75×75,100×100
Tilt Range: +75°~-45°
Swivel Range: +90°~-90°
Screen Rotation: +180°~-180°
Arm Full Extension: 611mm (24.1′)
Pole Height: 500mm (19.7′ )
Installation: Clamp,Grommet
Suggested Desktop Thickness: Clamp:10~50mm Grommet:10~50mm (Clamp:0.39’~2′ Grommet:0.39’~2′)
Quick Release VESA Plate: Yes
Cable Management: Yes
Accessory Kit Package: Normal/Ziplock Polybag

Product Last Updated: 10/04/2026
