Aten HDMI Over 2 Cat 5 Extender with MK Wall Plate, supports up to 1080p @ 40m, 8-segment equalization adjustment switch | VE807-AT-U

The VE807 HDMI/Audio Cat 5 Extender with MK Wall Plate is designed to be conveniently mounted in a one- gang junction box for the UK, Singapore, Hong Kong and other markets that apply MK type junction boxes. It extends HDMI and audio signals up to 60 meters over a Cat 5e/6 cable and supports widescreen formats ensuring excellent video quality. Supports superior video quality up to 1080p @ 60 Hz at a distance of 40 m; 1080i @ 60 Hz at a distance of 60 m

VE807R VE807T

Video
Max. Data Rate 6.75 Gbps (2.25 Gbps Per Lane)
Max. Pixel Clock 225 MHz
Compliance HDMI (3D, Deep Color) HDCP Compatible
Max. Resolutions / Distance Up to 1080p@40m; 1080i@60m

Audio 1 x HDMI Type A Female (Black)
Power 1 x Terminal Block (Green)

Environmental
Operating Temperature 0 – 50°C
Storage Temperature -20 – 60°C
Humidity 0-80% RH, Non-Condensing

Housing Metal

Product Last Updated: 17/07/2026

* Whilst we endevour to have the correct information on our products provided from the supplier/manufacturer errors do occur. If you would like to double check the information, please feel free to contact us and we will be more than happy to confirm information on the item prior to purchase. In the event that product information is incorrect due to information we received from our supplier or manufacturer, we do not take responsibility or be held liable for damage(s) or loss(s). We will work with you and do our best to make the best of a bad situation and work with our supplier(s) and/or manufacturer(s) to supply the correct information for the item purchased etc..
