Gigabyte nVidia GeForce RTX™ 4060 Ti WINDFORCE OC 8G, 2550 MHz, CUDA 4352, 18 Gbps, GDDR6, 128 bit, PCI-E 4.0, PSU 500W,DisplayPort 1.4a*2 HDMI 2.1a*2 | GV-N406TWF2OC-8GD

Gigabyte nVidia GeForce RTX™ 4060 Ti WINDFORCE OC 8G, 2550 MHz, CUDA 4352, 18 Gbps, GDDR6, 128 bit, PCI-E 4.0, PSU 500W,DisplayPort 1.4a*2 HDMI 2.1a*2

SPECIFICATION

Graphics Processing
GeForce RTX™ 4060 Ti (8GB)

Core Clock
2550 MHz (Reference Card: 2535 MHz)

CUDA® Cores
4352

Memory Clock
18 Gbps

Memory Size
8 GB

Memory Type
GDDR6

Memory Bus
128 bit

Card Bus
PCI-E 4.0

Digital max resolution
7680×4320

Multi-view
4

Card size
L=201 W=120 H=41 mm

PCB Form
ATX

DirectX
12 Ultimate

OpenGL
4.6

Recommended PSU
500W

Power Connectors
8 pin*1

Output
DisplayPort 1.4a*2
HDMI 2.1a*2

Accessories
Quick guide

KEY FEATURE

Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
3rd Generation RT Cores: Up to 2X ray tracing performance
Powered by GeForce RTX™ 4060 Ti (8GB)
Integrated with 8GB GDDR6 128bit memory interface
WINDFORCE cooling system
Protection back plate

The Ultimate Platform for Gamers and Creators
Powered by GeForce RTX 40 Series and DLSS 3

New Streaming Multiprocessors
Up to 2x performance and power efficiency

Fourth-Gen Tensor Cores
Up to 4x performance with DLSS 3 vs. brute-force rendering

Third-Gen RT Cores
Up to 2x ray tracing performance

WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features two 90mm unique blade fans, alternate spinning, 3 composite copper heat pipes directly touch the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.

SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.

HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a metal plate contact to ensure proper cooling.

PROTECTION BACK PLATE
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
