Intel® Xeon® W-2223 Processor, 8.25M Cache, 3.60 GHz, 4 Core, 8 Thread, Boxed, 3 Year Warranty

Intel® Xeon® W-2223 Processor, 8.25M Cache, 3.60 GHz, 4 Core, 8 Thread, Boxed, 3 Year Warranty

CPU Specifications
Total Cores 4
Total Threads 8
Max Turbo Frequency 3.90 GHz
Processor Base Frequency 3.60 GHz
Cache 8.25 MB
Bus Speed 8 GT/s
TDP 120 W

Memory Specifications
Max Memory Size (dependent on memory type) 1 TB
Memory Types DDR4 2666
Max # of Memory Channels 4
Max Memory Bandwidth 85.3 GB/s
Physical Address Extensions 46-bit
ECC Memory Supported ‡ Yes

Expansion Options
Scalability 1S Only
PCI Express Revision 3
PCI Express Configurations ‡ x4 | x8 | x16
Max # of PCI Express Lanes 48

Package Specifications
Sockets Supported FCLGA2066
Max CPU Configuration 1
TCASE 64°C
Package Size 45mm x 52.5mm

Advanced Technologies
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Optane™ Memory Supported ‡ No
Intel® Speed Shift Technology Yes
Intel® Turbo Boost Max Technology 3.0 ‡ No
Intel® Turbo Boost Technology ‡ 2
Intel® Hyper-Threading Technology ‡ Yes
Intel® Transactional Synchronization Extensions Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.2 | Intel® AVX | Intel® AVX2 | Intel® AVX-512
# of AVX-512 FMA Units 2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Intel® Demand Based Switching Yes
Thermal Monitoring Technologies Yes
Intel® Identity Protection Technology ‡ Yes
Intel® Volume Management Device (VMD) Yes

Security Reliability
Intel vPro® Eligibility ‡ Intel vPro® Platform
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) No
Intel® Memory Protection Extensions (Intel® MPX) Yes
Intel® OS Guard Yes
Intel® Trusted Execution Technology ‡ Yes
Execute Disable Bit ‡ Yes
Intel® Boot Guard Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Product Last Updated: 14/04/2025
